Waterproof LED Transformer directly used to meet your requirements of high voltage input source, and it will give you a stable 12 volts of power up to 100 watts. ??This is useful for applications where you don't want to use an electrical socket outlet. It accepts an input voltage from AC170-250V.


Our waterproof power supplies are completely sealed with Epoxy glue, covered by Aluminum metal cover and achieves a waterproof rate of IP67. ??This Waterproof LED Transformer ensures a good lighting effect and a long life time for all 12 volt LED products.

We suggest that it to be used with our LED garden lights, LED strips lights and Waterproof ridge strips.


GENERAL SPECIFICATIONS

Product Model Number: EV-PS-O-12V-100W
Safety Compliance: ROHS, CE, UL, cUL
IP Rating: IP67
Size: 65 mm x 38 mm x 165 mm
Weight: 650 grams
Cooling: Free air convection
Construction: Impact resistant aluminum enclosure case


INPUT SPECIFICATION

Input Voltage: Input Voltage: rating 100-250VAC
Input Frequency: 47-63Hz.



OUTPUT SPECIFICATION

Output Voltage: 12.0 Volts
Output Current: 8.33 Amps, 8330 mA
Output Wattage: 1000 Watts typical



How to select the right amperage for the LED strips?

Firstly you need to figure out the total Watts of your LEDs .

Suppose you are powering 5 meters of our LED Ribbon Strips which is SMD 5050 LED strips, 12V, 60LED/M, that means: 72W/Reel( 5 meters). You may need an waterproof transformer which is 72W/12=6A.

If you select a 12V, 6A waterproof transformer, it would be at the limit of its capabilities. The LED strips may not reach their full brightness potential, and the waterproof transformer may work harder than it should. In this case, it would be better to go with a 96W waterproof transformer (72W/0.8=90W ).

We suggest that the waterproof transformer should only be used 80% of its capacity, by doing this, the waterproof transformer can be used for a longer time.
